Technical specification of Youjoy Portable Hand Type Dental X-Ray
High-frequency chairside x-ray machine
Less radiation to the patient & operator
Compact & single-handed device 2ma tube current, ensures higher performance and high definition imaging Adopt canon tube with focus spot 0.4mm,
Anode angle 12.5°
The digitally controlled device provides higher accuracy & stability
Widescreen display for easy operation
Model: YOU98 (P)
70kv (±10%) Voltage
2ma (±20%) Current
100v – 240v rating voltage:
50hz – 60hz frequency
Canon d-045 tube
12.5° anode angle:
0.4 mm focal spot:
0.04 s-2.0 s approximate exposure time range
1 meter ≤ 0.25 mgy/h
1.7 kg machine weight Youjoy Portable Hand Type Dental X-Ray
30 percent rh ~ 75 percent rh relative humidity
Useable at diagnostic centers, and personal dental centers.
Easy to carry from one location to another location
Made in China
One Year Service Warranty
